TFL Series

Parameters

Part No.	Input Voltage	Output Power	Output Voltage	Output Current	Power Factor	Certificate	Dimension(mm)
TFL-12V030W-NDA	100-277VAC	30W MAX.	12VDC	2.5A	>0.95	UL/cUL/FCC/ Class 2/Class P/RoHS	L156W56H20mm [L6.1W2.2H0.79in.]
TFL-24V030W-NDA	100-277VAC	30W MAX.	24VDC	1.25A	>0.95	UL/cUL/FCC/ Class 2/Class P/RoHS	L156W56H20mm [L6.1W2.2H0.79in.]
TFL-12V060W-NDA	100-277VAC	60W MAX.	12VDC	5A	>0.95	UL/cUL/FCC/ Class 2/Class P/RoHS	L180W61H25mm [L7.1W2.4H1in.]
TFL-24V060W-NDA	100-277VAC	60W MAX.	24VDC	2.5A	>0.95	UL/cUL/FCC/ Class 2/Class P/RoHS	L180W61H25mm [L7.1W2.4H1in.]
TFL-12V096W-NDA	100-277VAC	96W MAX.	12VDC	8A	>0.95	UL/cUL/FCC/ Class P/RoHS	L205W61H25mm [L8.1W2.4H1in.]
TFL-24V096W-NDA	100-277VAC	96W MAX.	24VDC	4A	>0.95	UL/cUL/FCC/ Class P/RoHS	L205W61H25mm [L8.1W2.4H1in.]
