• TFL Series

    TFL Series

    ·Support isolate interface dimming 0-10V/1-10V/10V PWM/Rx dimming
    ·Full range input voltage 100-277VAC
    ·Soft dimming and flicker-free at any brightness
    ·Dimming range 0.1~100%,support multiple lights dimming
    ·High PF, high efficiency, low THD
    ·SELV and Class 2 design
    ·UL certification
    ·Suitable for dry and damp location
    ·Nominal lifetime up to 100,000 h
    ·5-year warranty
  • /upload/images/20240626/515f9ec94e963efc51db9e12b2c90114.png

Parameters

Part No.Input VoltageOutput PowerOutput VoltageOutput CurrentPower FactorCertificateDimension(mm)
TFL-12V030W-MDA100-277VAC30W MAX.12VDC2.5A>0.95

UL/cUL/FCC/

Class 2/Class P/RoHS

L156*W56*H20mm

[L6.1*W2.2*H0.79in.]

TFL-24V030W-MDA100-277VAC30W MAX.24VDC1.25A>0.95

UL/cUL/FCC/

Class 2/Class P/RoHS

L156*W56*H20mm

[L6.1*W2.2*H0.79in.]

TFL-12V060W-MDA100-277VAC60W MAX.12VDC

5A

>0.95

UL/cUL/FCC/

Class 2/Class P/RoH

L180*W61*H25mm

[L7.1*W2.4*H1in.]

TFL-24V060W-MDA100-277VAC60W MAX.24VDC2.5A>0.95

UL/cUL/FCC/

Class 2/Class P/RoHS

L180*W61*H25mm

[L7.1*W2.4*H1in.]

TFL-12V096W-MDA100-277VAC96W MAX.12VDC8A>0.95

UL/cUL/FCC/

Class P/RoHS

L205*W61*H25mm

[L8.1*W2.4*H1in.]

TFL-24V096W-MDA

100-277VAC96W MAX.24VDC4A>0.95

UL/cUL/FCC/

Class 2/Class P/RoH

L205*W61*H25mm

[L8.1*W2.4*H1in.]
